Neutrik B-Gauge GPO Bantam Jack Patch Lead. Van Damme Cables

£0.00

Quick Overview

Quality B gauge GPO bantam patchcords for use in B-Type jack-field patch bays. Including Moses and Mitchell, Neutrik, Switchcraft, Rean + many more.  Made using Van Damme 2 core and screen cable with a composite neoprene jacket for maximum flexibility and durability.

Availability: In stock

Check Prime Stock
Ship to: Worldwide
  • Black
  • Blue
  • Red
  • Yellow
  • Green
  • White
  • Purple
  • Orange
  • Grey
  • Black Boots
  • Red Boots
+£1.00

Characters left: 15

* Required Fields

£0.00

Details

  • Flexible Van Damme XKE Cable
  • Neutrik NP3TB 1/4" 'B-Gauge' GPO Plug. Black and Red available with above options.
  • Fully wired for 'Balanced' operation.
  • Manufactured using 4% silver solder.



The Truth behind Gold and Silver Connectors........
Silver is the better conductor however gold is highly resistant to corrosion so is favoured for its durability.

Additional Information

Prime Link N/A
Cable Capacitance 56 pF/m core to core
Cable Resistance Conductor Ohm/Km <85
Cable Conductor Bare silver plated UPOFC wire Stranding 7 x 0.10mm + Bare UPOFC wire Stranding 21 x 0.10mm
Cable Jacket Flexible PVC/Neoprene composite. Overall diameter 6.35mm
Brand.... Van Damme
Application.... Studio Grade
Terminated with.... GPO Bantam to GPO Bantam
Metal Type.... Silver Plated
Poles 3 Pole
Works with.... Bantam
Special Attribute N/A
Multicore Options.... No
Wireless System No
