Sommer Binary 234 DMX & AES 110hm 5 Pin XLR Lead. UV-resistant.
As low as
£13.30
In stock
SKU
5FX-BAG-SO.BINARY.234.PRNT-5MX-BAG
Flexible and hard-wearing Tour-Grade digital AES and DMX signal cables from Sommer. Terminated with industry standard 5 Pin XLRs from Neutrik. These only have Pins 1/2/3 wired, which is the typical pin-out for DMX cables. Pins 4/5 were initially implemented in DMX for a check back channel, but the technology was never deployed. They also help to differentiate from regular audio XLR cables.
Flexible and hard-wearing Tour-Grade digital AES and DMX signal cables from Sommer. Terminated with industry standard 5 Pin XLRs from Neutrik. These only have Pins 1/2/3 wired, which is the typical pin-out for DMX cables. Pins 4/5 were initially implemented in DMX for a check back channel, but the technology was never deployed. They also help to differentiate from regular audio XLR cables.
Swinging with your girlfriend...
like Tarzan in the jungle. With this cable you could just do that: it can take a lot of tugging, bending, and rough wear and tear. This is important when installing it in sharp-edged lighting trusses.
The Binary 234 AES/EBU MKII is an outstanding cable for the transmission of digital signals in the 110 Ω AES/EBU and DMX data format. Its shielding is provided by an aluminum-vaporised fleece and a helical copper mesh screen with 100 % coverage. So it offers a very good protection against electric and magnetic interferences. This cable ensures an error-free data transfer over distances of up to 1000 metres. With the Binary 234 AES/EBU MKII you’ll be on the safe side.
- Part Number - 520-0051
- Compatible with Line 6 L6 Digital LINK Cable and Balanced audio connections
- Neutrik NC5FXX-BAG and NC5MXX-BAG connectors (Pins 1/2/3 wired)
- Manufactured using 3.5% silver solder
Advantages:
- AES/EBU- and DMX-conformant, highly flexible
- Very good shielding due to the use of a helical copper mesh screen plus
- an aluminium-vaporised fleece
- Extremely rugged due to the special tough jacket
- Only a little more expensive than a standard microphone cable
Application:
- Networking of scanners, lighting systems, digital mixing consoles etc.
- For indoor and outdoor installation
- Connection of digital audio amplifiers, DAT recorders etc.
| Delivery Speed | Made to Order - Next Day Delivery Available |
|---|---|
| Cable Capacitance | Core to shield. per 1m - 115pF |
| Cable Resistance | Impedance 110Ω |
| Cable Conductor | OFC oxygen free copper |
| Cable Screening | Copper spiral shielding + aluminum steamed fleece |
| Cable Jacket | UV-resistant PVC |
| Overall Diameter | 6.2mm |
| Cable Brand | Sommer |
| Application | Tour & Studio Grade |
| Contact Material | Silver Plated |
| Number of Contacts | 5 Pole |
