These Industry Standard Connectors offer a high reliability connection, ideal where a large number of wires are interconnected to a panel. The hermaphroditic contact design provides a gas tight connection with superior shock and vibration resistance. Ease of mating is facilitated with the use of an actuating screw and lock nut, and polarized hardware.

Thermoplastic polycarbonate male connector insert (pins visible)
NB Crimp or solder contacts supplied separately.
Cable female inserts have a threaded actuating screw and mate with male ‘panel’ types.
Can be panel mounted or cable mounted using the relevant EDAC cover.
Suitable in a range of applications including, broadcast, automotive, transportation, telecommunications, and energy.

More Information
Delivery Speed	Next Day delivery available if 'In Stock'
Number of Contacts	90 Pole
Pack Quantity	Pack of 1

Only registered users can write questions. Please Sign in or Create an account

Write Your Own Review

Only registered users can write reviews. Please Sign in or create an account

EDAC Connector Data Sheet.pdf

90 pin Male Edac Panel Mount Connector

Due to exceptionally high demand and the built-to-order nature of our products, we are currently unable to offer expedited or next-day shipping services. Current manufacturing lead times are approximately 6–7 working days, followed by 1–2 working days for delivery.

All orders are being processed as quickly as possible in the order they are received. We appreciate your patience and understanding while our team works to maintain the quality and reliability of every assembly we produce.
