Neutrik B-Gauge GPO Bantam Jack to TRS Jack Patch Lead. Van Damme Cables

Quality B gauge GPO bantam patchcords to regular 6.35mm TRS for use in B-Type jack-field patch bays. Including Moses and Mitchell, Neutrik, Switchcraft, Rean + many more. Made using Van Damme 2 core and screen cable with a composite neoprene jacket for maximum flexibility and durability.
Quality B gauge GPO bantam patchcords to regular 6.35mm TRS for use in B-Type jack-field patch bays. Including Moses and Mitchell, Neutrik, Switchcraft, Rean + many more. Made using Van Damme 2 core and screen cable with a composite neoprene jacket for maximum flexibility and durability.
Flexible Van Damme XKE Cable
Neutrik NP3TB 1/4" 'B-Gauge' GPO Plug. Black and Red available with above options
Neutrik Regular NP3X 1/4" TRS jack
Fully wired for 'Balanced' operation.
Manufactured using 4% silver solder.
The Truth behind Gold and Silver Connectors........
Silver is the better conductor however gold is highly resistant to corrosion so is favoured for its durability.
Delivery Speed | Made to Order - Next Day Delivery Available |
---|---|
Cable Capacitance | 56 pF/m core to core |
Cable Resistance | Conductor Ohm/Km <85 |
Cable Conductor | Bare silver plated UPOFC wire Stranding 7 x 0.10mm + Bare UPOFC wire Stranding 21 x 0.10mm |
Cable Screening | - |
Cable Jacket | Flexible PVC/Neoprene composite. OD - 6.35mm |
Overall Diameter | - |
Cable Brand | Van Damme |
Application | Tour & Studio Grade |
Contact Material | Silver Plated |
Number of Contacts | 3 Pole |
