Rean Length 1 NSB1C-8.0 Stage Box 8 IN
Rean Length 1 NSB1C-8.0 Stage Box 8 IN
Buy 10 for
£56.53
each and save 5 %
Buy 20 for
£53.55
each and save 10 %
Buy 50 for
£50.58
each and save 15 %
Buy 100 for
£47.60
each and save 20 %
Type C, length 1, 8 IN (female/send)
Width: 87 mm, height: 77 mm, length: 132 mm
Supplied as disassembled set comprising of all hardware parts including plates, profiles, strain relief, end pieces and screws. Labels for channel numbering not included.
Technical Information
Product
Title - NSB1C-8/0
Electrical
Contact resistance - < 5 mΩ
Dielectric strength - 0.5 kVdc
Insulation resistance - ≥ 1 GΩ
Rated current per contact - 2 A
Mechanical
Cable O.D. - 10 - 14 mm multicore
Insertion force - ≤ 10 N
Withdrawal force - ≥ 10 N
Lifetime - > 1000 mating cycles
Wiresize - 0.22 and 0.14 mm²
Wiresize - 24 and 26 AWG
Material
Shell - Aluminium
Quad plates - POM
End pieces - Thermoplastic
Environmental
Temperature range - -25 °C to +70 °C
