Syntax SSX Male Socapex Compatible 19 Pole Cable Mount Connector
£56.63
Available for Pre-Order
SKU
MAINS_Syntax.SOCA.MALE.CABLE(1)
Multibuy discounts calculated at checkout
- Buy 5 for £53.80 each and save 5%
- Buy 10 for £50.97 each and save 10%
- Buy 15 for £48.14 each and save 15%
- Buy 20 for £45.30 each and save 20%
The redesigned SSX 19-pin connector featuring more stable coupling and faster wiring. Syntax have made it indestructible, safer and more reliable. Socapex SL 419 series compatible. UL Compliant
The redesigned SSX 19-pin connector featuring more stable coupling and faster wiring. Syntax have made it indestructible, safer and more reliable. Socapex SL 419 series compatible. UL Compliant
*Silver Pins Included in Packaging*
The Syntax® SSX series, designed for professional applications and totally compatible with standard Soca 19-pin series connectors, is extremely robust being made of thick wall construction machined aluminum alloy, with hard wearing black painted or anodized finish. The thermoplastic insulating insert enables the use of removable contacts, either crimp or solder. The unit is completely IP67 watertight when mated. Electrical safety and compliance are guaranteed by internal insulation of the shells, obtained through a safety insulating sleeve preventing electric shock, as well as “first make last break” ground contacts. Grounding rings allow bussing of the ground contacts. Locking rings and backshells are designed for easy handling.
Technical Information
Ingress protection - IP67-IEC 529 norms
Salt atmosphere resistance - 96 h IEC 68-21-11
Operating temperature - -55°C to +125°C
Shell material - machined aluminium alloy
Finish - black painted or anodized
Inserts - Thermoplastic rubber
Cable gland on inline versions - Metric M40 thread
Cable gland on multiway versions - Metric M40 (4-way) or M50 (6-way and 8-way) thread
Contacts - Silver or gold plated removable for crimping or soldering
Typical applications
- Electrical power systems
- Power distribution
- Outdoor concerts and sporting events
- Outdoor broadcasting
- Theatres
- Mobile generators
- Industrial vehicles
- Railway installations
- Military installations
- Load banks
- Backup power systems
- Electrical power supply companies
- Heavy industry
| Delivery Speed | Next Day delivery available if 'In Stock' |
|---|---|
| Connection Type | Socapex |
| Mounting Method | Cable Mount - Solder |
| Contact Material | Silver Plated |
| Number of Contacts | 19 Pole |
| Current Rating | 20 amps |
| Voltage Rating | 230-240v |
| IP Rating | IP67 |
| Pack Quantity | Pack of 1 |
