32amp 230V 2P+E IP44 Straight Flush Mount Panel Mount Appliance Male INLET PCE (623-6)

In stock
We have 32 items in stock!
  • Buy 10 for £10.67 each and save 5%
  • Buy 20 for £10.11 each and save 10%
  • Buy 50 for £9.55 each and save 15%
  • Buy 100 for £8.98 each and save 20%

High quality chassis mount connectors made from POLYAMIDE 6, see listing description for full technical spec

PCE is specialized in the production of industrial plugs, sockets and power distribution boxes. During the past few years, the company has gone through a phase of rapid development and is now one of the world’s leading manufacturers of CEE IEC60309 plugs, sockets and accessories.

  • Screw terminals
  • Brass contacts
  • 2.5mm to 6mm Wiring
  • Housing material PA6
  • 32A 230V 2P+E IP44
  • Flange Size 70 x 70 mm
  • Fixing Centre 56 x 56 mm

CEE-plugs and sockets with rated currents 16A and 32A must meet the system of protection IP44 or IP67;

PCE plugs and sockets are produced from POLYAMIDE 6. The main characteristics of this material are:
·        excellent impact resistance combined with high rigidity and solidity,
·        high thermal stability (self-extinguishing),
·        very good insulating qualities,
·        high disruptive strength,
·        high abrasion resistance,
·        high weathering resistance,
·        very good chemical resistance to various chemicals,
·        free from cadmium and halogen (fluorine, chlorine, bromine, jodine, astatine)
·        conform to RoHS-directiv 2011/65/EU

More Information
Connector Type Mains Distribution
Mains Connector Type 32amp CEEform
Manufacturer PCE
Metal Type.... Solid Brass
Poles 3 Pole
Current Rating (amps) 32
Housing Type POLYAMIDE 6
