Neutrik Isolated BNC chassis connector, feedthrough in nickel D-shape housing. NBB75DFI
£8.95
In stock
We have 82 items in stock!
SKU
CHASSIS_NBB75DFI
- Buy 10 for £8.50 each and save 5%
- Buy 20 for £8.06 each and save 10%
- Buy 50 for £7.61 each and save 15%
- Buy 100 for £7.16 each and save 20%
Neutrik's BNC chassis connectors offer a true 75 Ω design for serial and digital (HD) signals. The machined brass connector body provides an extremely rugged and non-abrasive connection over long term use and is in addition recessed and therefore well protected in a D-shape housing (audio industry standard).
Neutrik's BNC chassis connectors offer a true 75 Ω design for serial and digital (HD) signals. The machined brass connector body provides an extremely rugged and non-abrasive connection over long term use and is in addition recessed and therefore well protected in a D-shape housing (audio industry standard).
NBB75DFI
Isolated BNC chassis connector, feedthrough in nickel D-shape housing
Features & Benefits
- Gold plated cage type center contact
- True 75 Ω design meets the stringent HD requirements
- Isolated panel mount (solves potential grounding problems and prevents common-mode influence with other connections conducted over the same panel ground potential)
- Standard D-shape housing - provides flush mounting and protection from demage
- Color coding possible
New cage type contact
- Closed contact design - extremely robust
- Gold plated cage type clip - best possible shielding and lowest contact resistance
Title - NBB75DFI
Connection Type - BNC 75 Ω
Gender - female
Electrical
Signal Type - HD, SDI, Video, AES/EBU, Composit, YUV, RGB, RGBH, RGBHV
Contact resistance - ≤ 3 mΩ (inner)
Contact resistance - ≤ 2 mΩ (outer)
Dielectric strength - 1,5 kVdc
Impedance - 75 Ω
Insulation resistance - > 5 GΩ
Rated voltage - <50 V
VSWR
≤1.03/>37 dB up to 1 GHz
≤1.05/>32 dB up to 2 GHz
≤1.08/>28 dB up to 3 Ghz
Mechanical
Insertion force - < 25 N
Lifetime - > 1000 mating cycles
Locking device - Bayonett
Mounting direction - Front mounting
Chassis shape - D
Material
Contacts - Brass (CuZn39Pb3), 0.2 µm AuCo (Center contact)
Insert - PTFE
Shell - Polyacetal (POM) (Insulation Sheell)
Shell plating - Optalloy®
D-Shape housing - Zinc diecast (ZnAl4Cu1) gal Ni plating
| Delivery Speed | Next Day delivery available if 'In Stock' |
|---|---|
| Mounting Method | Panel Mount - Feedthrough |
| Series Range Name | CrimpType 75ohm |
| Contact Material | Gold Plated |
| Number of Contacts | 2 Pole |
| Pack Quantity | Pack of 1 |
| Manufacturer URL | Download Data Sheet |
| Data Sheet URL | Download Data Sheet |
